CAT5e Shielded Ethernet Cable Riser Rated

Description

CAT5E Shielded Riser Rated

Category 5e Shielded Riser Rated cable is the ideal cable for residential and commercial indoor installations that do not require Plenum rated cable. Shielded to protect against electromagnetic interference (EMI). Made of solid copper conductors to meet and exceed ANSI/TIA cabling standards.

  • High-Performance Data Communications Cable
  • Tested to 350MHz for excellent Attenuation and Crosstalk characteristics
  • PVC Jacket, Riser (CMR) Rated
  • CAT5e Shielded Twisted Pair (F/UTP) Cable
  • 4-Pair Easily Identified Color-Striped Pairs
  • 24AWG Solid Bare Copper Conductors
  • Exceeds ANSI/TIA 568 C.2 and ISO 11801 specifications
  • ETL Listed, RoHS Compliant
  • Supplied in 1,000ft Pull Boxes

Riser Rated (CMR)
CMR cable is used in vertical applications such as runs between floors or through cable risers. Vertically installed Riser rated cables, when subjected to fire, prevent fire from travelling upwards. CM rated cables are not suitable for such applications.

Solid or Stranded?
Solid Cable is recommended for internal use, such as in between walls, between wiring closets, and for lengths over 25 feet. Recommended for use up to 100 meters (328 feet).

Stranded Cable is flexible alternative to solid cable. It is most commonly used to connect PC's and other end devices to routing devices in residential locations. Because of higher attenuation (signal fall-off) it is best for use in runs of 25 feet or less.

Product form

SKU: 057-468/S/BK

CAT5e Shielded Ethernet Cable Riser Rated

CAT5E Shielded Riser Rated Category 5e Shielded Riser Rated cable is the ideal cable for residential and commercial indoor installations... Read more

$175.00

    • Guaranteed secure & safe checkout.

      shop pay
    • Shipped today? Order within: Jun 15, 2026 23:59:00 -0700
    • Free shipping on all orders above $2,500
    • No hassle returns, 30 days return

    Description

    CAT5E Shielded Riser Rated

    Category 5e Shielded Riser Rated cable is the ideal cable for residential and commercial indoor installations that do not require Plenum rated cable. Shielded to protect against electromagnetic interference (EMI). Made of solid copper conductors to meet and exceed ANSI/TIA cabling standards.

    • High-Performance Data Communications Cable
    • Tested to 350MHz for excellent Attenuation and Crosstalk characteristics
    • PVC Jacket, Riser (CMR) Rated
    • CAT5e Shielded Twisted Pair (F/UTP) Cable
    • 4-Pair Easily Identified Color-Striped Pairs
    • 24AWG Solid Bare Copper Conductors
    • Exceeds ANSI/TIA 568 C.2 and ISO 11801 specifications
    • ETL Listed, RoHS Compliant
    • Supplied in 1,000ft Pull Boxes

    Riser Rated (CMR)
    CMR cable is used in vertical applications such as runs between floors or through cable risers. Vertically installed Riser rated cables, when subjected to fire, prevent fire from travelling upwards. CM rated cables are not suitable for such applications.

    Solid or Stranded?
    Solid Cable is recommended for internal use, such as in between walls, between wiring closets, and for lengths over 25 feet. Recommended for use up to 100 meters (328 feet).

    Stranded Cable is flexible alternative to solid cable. It is most commonly used to connect PC's and other end devices to routing devices in residential locations. Because of higher attenuation (signal fall-off) it is best for use in runs of 25 feet or less.
